Pogo pin connector is used in smart switch panel.bipolar electrode Production

　　With the development of the times, people's awareness of environmental protection has gradually increased, new energy vehicles have become a development trend, and the development of electrical connectors has gradually become the mainstream. The development and R&D of new energy is bound to become an irresistible trend. Electric vehicles are also an industry that is involved in this field. The composition of the electrical connector includes pogopin, pin jack, and spring thimble.

　　Pogopin as an important part of the connector as a connector, its main function is to conduct electricity and transmit information. Its function directly affects the operation of the entire connector. Therefore, the pogopin must be designed reasonably in the entire structure to achieve the basic functional significance. Below I will break it down to decompose its principle.

　　The smart switch is composed of a bottom box, a middle box and a front decorative panel. When installing on the wall, the bottom box and the wall need to be formed into one body through concrete. The middle box and the bottom box are fixed by screws on both sides and then locked. Together, the front decorative panel is connected by a tenon and a middle box card. In this way, most of the electronic components are designed to be installed in the middle box, and connected through the connector and the front decorative panel for communication and power supply. If the connector of this part is a wire-to-wire connector, then during the later maintenance, if the front decorative panel is manually removed, the connection cable is likely to be disconnected.

　　Therefore, this part of the smart switch panel is very suitable for the application of the POGO PIN connector. This is because the head of the POGOPIN connector is flexible and can directly contact the PCB copper foil of the front panel without additional wire connection. It can effectively avoid the disconnection of the connecting cable when the front panel is removed manually, and there is no need to use the hand of the worker to plug and unplug the connector, which greatly improves the efficiency of disassembly and assembly of the front decorative panel in the project. It shortens the customer's engineering installation cycle and reduces the maintenance cost in the later period.
