Manufacturing method of magnetic power adapter and magnetic connector.level electrode Processing

　　The utility model patent provides this kind of magnetic connector, which includes a first male head, a next male head and a mobile phone charging cable connecting the first male head and the second male head. The two sides of the mobile phone charging cable form the first Female head and 2nd female head. The first male connector produces a second male connector with a second male connector, the first female connector produces a first female connector, and the second female connector produces a second female connector. The joint part has the same structure as the next head joint part. The joint part of the first female head has the same structure as the second female joint part; the first male joint part and the first female joint part or the second female head Connecting part, a magnetic connector between the second female connector and the second female connector or the first female connector.

　　The first male connector and the second male connector respectively form a punch, and several conductive loops are formed on both sides of the punch.

　　More powerfully, a concave is formed in the joint of the first female head and the joint of the second female head, and one side is generated in the dent. The joints are arranged in a row, and the protrusions are inserted to the joint. Prompt the junction and the conductive ring to touch and turn on and off.

　　More powerfully, the conductive ring has sympathy, in which the core conductive ring touches an independent terminal, and the other conductive rings touch the connecting terminal. The first and second male heads above each include a Pcb component for connecting to the male head software, a Pcb component connected to the male head software, and a first magnet ring that covers the Pcb component. A part of the Pcb component is extended in the Pcb The first magnet ring on the outside of the module.

　　What's even stronger is that the guide head component produces a precise positioning hole, the guide foot produces a precise positioning column, and the precise positioning column is inserted into the precise positioning hole.

　　It can be better that the first female header and the second female header each include a terminal block connector, a switching power supply switchboard electrically connected to the radio frequency connector of the connector, and a second magnet ring of the ring sleeve connector. 2 The magnet ring is located above the connector of the connector, and a concave groove is formed around the outer edge of the connector. More powerfully, the terminal of the terminal connector is S-shaped.

　　Conversely, this utility model patent provides such an adapter, which includes an adapter and a male head connected to the adapter, a Pcb component connected to the male head software, and a first magnet ring of the ring sleeve Pcb component. Part of the above-mentioned Pcb component is expanded to the first 1 The magnet ring is produced on the boss. A conductive ring is formed on the outside of the punch. More powerfully, the male connector is integrated into the adapter.

　　Compared with the original technology, the male head of the magnetic-absorbing radio frequency connector of this utility model can be magnetically connected with the female head on the side of the mobile phone charging line, and the magnetic-absorbing power adapter composed of the male head can be immediately attracted to the female head of the mobile phone charging line. Magnetic connection is easy to use and does not need to be plugged in frequently, preventing damage, embrittlement and other problems.
