What is the structure of the pogo pin spring thimble connector?bipolar electrode Manufacturing

　　Pogo pin spring thimble connector is a kind of precision electronic component required by almost all electronic products nowadays. It is widely used by most electronic manufacturers due to its various shapes and various performances. So what is the structure of the pogo pin spring thimble connector?

　　5G radio frequency pogo pin spring thimble connector is mainly composed of needle shaft, spring and needle tube. The advantages of this Pogo pin spring thimble connector design are that it can save more space, have a longer life, and the distance between points is smaller.

　　Among them, the needle shaft is an important part of the pogo pin spring thimble connector. The needle shaft is divided into back drilling and bevel cutting. Designed according to different requirements. The small size of the back-drilled hole requires electronic equipment with a smaller connector size. The back drill pin shaft can meet the manufacturer's requirements for springs. Even if the spring exceeds the length of the needle tube, the needle shaft can be hollowed out to give the spring more space. The oblique cutting edge mainly allows the needle shaft to contact the needle tube at a larger level, ensuring stable and low connection resistance.
