The easiest way to install pogo pin spring thimble

　　Nowadays, electrical and electronic products are developing in the direction of being delicate, easy to install and having a long service life. The small size and retractable design of pogo pin pogo pins can solve the needs of today's electrical and electronic products. With the increasing number, various pogo pin pogo pin manufacturers have sprung up in the market. Many times, if we want to choose a more suitable product, we need to know in advance. Today, the editor will tell you how to install the pogo pin spring thimble

　　1. The spring thimble is usually installed in a stable way, and the bottom of the needle tube is a flat bottom design, so we can use vertical or horizontal package, which makes it easier to solder with the PCB. Also, some needles have locating pins on the end so there is no offset and it will work better.

　　2. Ordinary plug-in package for easy welding. In addition, we often use tailbend plug-in packages, which also gives pogo pin manufacturers more options in terms of space utilization.

　　3. Mainly adopts double-head double-acting design, which is more suitable for connection without welding pressure, allowing engineers to have more space flexibility when making two-way board-to-board connections.
