Pin header and female connector series

　　Pin header and female PH: 0.8mm1.0mm1.27mm2.0mm2.54mm, board-to-board 0.5mm0.8mm, FPC seat, USB interface, USB cable and a series of products.

　　1. PIN Header: The pitch is PH: 0.8mm/1.0mm/1.27mm/2.0mm/2.54mm

　　2. Female Header: Pitch: PH: 0.8mm/1.0mm/1.27mm/2.0mm/2.54mm 3. Board to Board: Pitch: PH: 0.5mm/0.8mm groove

　　4. FPC series: pitch is PH: 0.5mm thickness is 1.2mm (new product)

　　5. Simple horn series (Box Header): pitch: PH: 1.27mm/2.0mm/2.54mm

　　6. Traditional Ejector Header: Spacing: PH: 1.27mm/2.0mm/2.54mm

　　7. Memory Card Connector: CF/SD/MS/MMC/SMC+XD/SIM
