What exactly does the pogo pin do?gene probe Processor

　　With the development of the times, people's awareness of environmental protection has gradually increased, new energy vehicles have become the trend of development, and the development of electrical connectors has gradually become the mainstream. The development and research and development of new energy will become an irresistible trend. Electric vehicles are also an industry that players in this field are involved in. The composition of the electrical connector includes a pogopin, a pin jack, and a spring thimble.

　　As an important part of the connector, pogopin is mainly used to conduct electricity and transmit information. Its function directly affects the operation of the entire connector. Therefore, the design of pogopin in the whole structure must be reasonable in order to achieve the meaning of basic functionality. Below I will break it down and break down its principles.

　　As an important part of the connector, pogopin is mainly used to conduct electricity and transmit information. Its function directly affects the operation of the entire connector. Therefore, the design of pogopin in the whole structure must be reasonable in order to achieve the meaning of basic functionality. Below I will break it down and break down its principles.

　　Needle: Needle requires a smooth surface into a small round hemisphere.

　　Bevel: In order to ensure that the needle is in 100% contact with the needle tube during operation, we cut the end of the needle and the spring in contact with a bevel. This design concept can ensure that the low and stable contact resistance can absolutely guarantee the stable conduction of the product. This design of counter-drilling is the best choice for small size connectors, which can meet customer's elastic requirements.
