Determinants of the price of pogo pins

　　The pogo pin consists of a needle, a needle tube and a spring. Although the structure of the pogo pin is simple, the price evaluation of the pogo pin is very troublesome. Seeing this, you will definitely say that a structure that looks so simple does not need a price assessment. In fact, the structure of the pogo pin is simple, but it is not easy to make. Next, the editor of

　　Electronics will tell you the price of the pogo pin, and what is the manufacturer based on.

　　1. According to the volume of the pogo pin connector

　　Because the larger the volume of the pogo pin and the longer the diameter, the more material is consumed; the price will naturally be more expensive. At the same time, if the volume of the pogo pin is too small, the precision requirements are too high, and the price will rise. At this time, the manufacturer will consider the price from the design and production time. If the volume of the pogo pin is too small, the design requirements are very strict and the labor consumption is also very long. of.

　　2. According to the process requirements of the pogo pin

　　Take a pogo pin 2.0mm long and a single needle with a diameter of 1.5mm as the standard to give an example. When the needle has no special treatment, the price is more affordable. If the needle needs to be punched or another special process is required, this time Prices will go up. There are also many kinds of needle tubes for pogo pins: double-ended single needle, single needle with tail, side welding single needle and surface mount single needle, among which the price of surface mount single needle is the most affordable. And other processes are more difficult than the surface-mounted single needle process.

　　3. According to the thickness of the electroplating film of the pogo pin

　　The electroplating of the pogo pin is a very important procedure. When applied to different products, there are different requirements for the electroplating of the pogo pin. When the customer requires the product to withstand high current, we need to plate a thicker gold layer and different internal designs to meet the requirements. Customers' product requirements to ensure better product quality and higher product requirements. Of course, the price of pogo pins with a thicker gold layer is relatively higher.
