Application of board-to-board connector on mobile phones

　　Recently, a new board-to-board connector was discovered. It consists of two male and female connectors with the same structure. Each male and female connector has an insulator, and the insulator is one male and one female. Several male terminal grooves are opened on the male body part, and there is a male terminal in the male terminal groove; a thousand female terminal grooves are opened on the female body part, and the female terminal grooves have a receiving cavity and One female terminal.

　　Thousands of buckle slots are opened on the insulating body, and buckles are installed in the buckle slots. A new type of board-to-board-to-board connector, which provides connection force through the interlocking force of thousands of buckles on two female connectors, and then maintains a firm electrical connection between the female end and the male end .

　　With the development of smart phones, the requirements for skills are getting higher and higher, especially for flat-panel connectors used on mobile phones. First, they must have flexible connections and strong corrosion resistance, and secondly, they do not need. Welding and installation are convenient, and there is no fire hazard.

　　With people's awareness of product thickness and higher and higher requirements for connectors, connectors are getting thinner and thinner, and new requirements are put forward for the connection process. For individual products that have not reached the height, how to ensure the thickness of the gold plating of the product and the use of tin-free soldering when applying tin. This has become a key miniaturization issue.
