Probe Personalized Testing Solutions

　　Tools make an important contribution to safe and precise testing. Only by properly installing the socket and probe, it is possible to ensure a smooth test. Different tools and bits are available depending on the sockets and spring probes to be installed.

　　Installation of the needle cover: Press the needle cover into the contact support plate, and adjust the installation height variably through the retaining ring or embedding the pressing ring.

　　Probe High Frequency Needle Installation Tool

　　Installation of the probe: According to different specifications, use a suitable tool to press and screw the spring probe into the needle cover. Provides optimally adjusted bits according to the probe tip type and its diameter

　　A. Test probe:

　　Spring probes are used in different industries for precise and repeatable inspection of electronic components. INGUN's product range for spring probes is second to none in the world.

　　B. Test fixture:

　　From manual, pneumatic and vacuum driven test fixtures, right up to special adjustments, INGUN develops and produces test fixtures for all common test systems. Test fixtures can be inspected at different production stages using optical measuring devices.
