pogo pin features and structure description

　　It has different appearance depending on the application, but overall the pogo pin has a precision spring structure inside. The surface of the product is generally gold-plated, and the spring should also be gold-plated when the process is required. Thimble to achieve electricity or conduction, most of the oblique downward contact with the copper wall, spring bear a small amount, so the copper sleeve wall smooth. The electrical properties will actively seek the path with the lowest resistance to conduct the current. If the POGOPIN factory makes a non-oblique section, but the bottom is flat, most of the current will be conducted through the spring, and the requirement for the spring will be very high.

　　In order to meet special customer requirements, innovative spring needle connector self-developed standard specifications such as: 1.27Pitch(2-30 Pin), 2.0pitch(2-72 Pin), 2.54pitch(2-128 Pin), 3.0pitch(2-48 Pin) and other single-row/double-row/male/female connector specifications. At the same time, we provide one-stop customized solutions, which can be customized according to the special needs of customers:

　　1, shape: round/multi deformation/fan type and other special type;

　　2, spacing: (>1.27mm); Pin number (> 2 pin);

　　3, assembly style: SMT, DIP, 90 bending, welding line, etc.

　　4, positioning mode: concave and convex slot, sealing ring, clamping lock, positioning ear, positioning column, etc.;

　　5, support material: PA 66, PA9T, LCP, HTN, PBT, ABS, ABS+PC, etc.

　　6, the holder color can be customized according to Pantone color card;

　　7, transfer extension: PCBA, wiring harness, FPC, 1/0 connector, base, etc.

　　8, products meet: RoHS 2.0, HF, CP 65, REACH, NP, EN 1811, no magnetic, etc.
